• 2 x PCIe 4.0/3.0 x16 slot(s)*
  - Intel® 11th Core™ processors support PCIe 4.0 x16 or x8/x8 or x8/x4 mode(s)

• 1 x PCIe 3.0 x16 slot (supports x4 mode)**
• 1 x PCIe 3.0 x1 slots

Конектори:

• Вентилатор и охлаждане:
• 1 x 4-pin CPU Fan header(s)
• 1 x 4-pin CPU OPT Fan header(s)
• 1 x 4-pin AIO Pump header(s)
• 3 x 4-pin Chassis Fan header(s)
• 1 x 4-pin H_AMP Fan header(s)
• 1 x W_PUMP+ header(s)
• 1 x 2-pin Water In header
• 1 x 2-pin Water Out header
• 1 x 3-pin Water Flow header
• Свързани с мощността:
• 1 x 24-pin Main Power connector
• 2 x 8-pin +12V Power connector
• Свързани със съхранението:
• 4 x M.2 slots (Key M)
• 6 x SATA 6Gb/s ports
• USB:
• 1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C®)
• 2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports
• 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
• Други:
• 3 x AURA Addressable Gen 2 header(s)
• 1 x AURA RGB header(s)
• 1 x FlexKey button
• 1 x Front Panel Audio header (AAFP)
• 1 x ReTry button
• 1 x Speaker header
• 1 x SPI TPM header (14-1pin)
• 1 x Start button
• 1 x 10-1 pin System Panel header
• 1 x Thermal Sensor header

Съхранение:

Supports 4 x M.2 slots and 6 x SATA 6Gb/s ports

Intel®11th и 10th поколение:

• M.2_1 slot (Key M), type 2242/2260/2280/22110
• M.2_2 slot (Key M), type 2242/2260/2280 (M.2_2 shares bandwidth with PCIEX16_1 and PCIEX16_2. When M.2_2 is enabled, PCIEX16_1 will run at x8 mode and PCIEX16_2 will run at x4 mode.)

Intel® Z590 Chipset:

• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
• M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
• 6 x SATA 6Gb/s ports

Памет:

• 4x DDR4 (Dual channel)
• Max Memory Size: 128GB

DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

• Архитектура с две канални памети
•  Intel Extreme Memory Profile
