Интерфейси:

• 1 x PS/2 мишка
• 1 x PS/2 клавиатура
• 1 x D-Sub
• 1 x DVI-D
• 1 x HDMI
• 1 x USB 2.0 Port (поддържа ESD защита (ASRock Full Spike Protection))
• 4 x USB 3.0 Type-A Ports (поддържа ESD защита (ASRock Full Spike Protection))
• 1 x USB 3.0 Type-C Port (поддържа ESD защита (ASRock Full Spike Protection))
• 1 x RJ-45 LAN Port с LED (ACT/LINK LED и SPEED LED)
• HD аудио жакове: вход / преден говорител / микрофон

Слотове за разширение:

• 2 x PCI Express 3.0 x16 Slots (PCIE1: x16 mode; PCIE4: x4 mode)
• 2 x PCI Express 3.0 x1 Slots (Flexible PCIe)
• Поддържа AMD Quad CrossFireX™ и CrossFireX™

Конектори:

• 1 x Print Port Header
• - 1 x COM Port Header
• 1 x TPM Header
• 1 x Chassis Intrusion and Speaker Header
• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
• 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))

Съхранение:

• 6 x SATA3 6.0 Gb/s Co
• nnectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 15 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug
• 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
• 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s)

Памет:

• 4 цокъла DDR4 DIMM, поддържащи до 64 GB системна памет
• Поддръжка на модули памет DDR4 3600+(OC)/3200(OC)/2933(OC)/2800(OC)/2400/2133 non-ECC, небуферирана памет

*7th Gen Intel CPU поддържа DDR4 до 2400; 6^th Gen Intel CPU поддържа DDR4 до 2133.

Комплектът съдържа:

• Quick Installation Guide
• Support CD
• I/O Shield
• 2 x SATA Data Cables
• 2 x Screws for M.2 Sockets
