• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 6x SATA 6Gb/s connectors
• 2x M.2 slots (M-Key)
• 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB Gen 1 ports)
• 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1x 4-pin CPU fan connector
• 1x 4-pin water-pump fan connector
• 2x 4-pin system fan connectors
• 1x Front panel audio connector
• 2x System panel connectors
• 1x Chassis Intrusion connector
• 1x Clear CMOS jumper
• 1x TPM module connector
• 1x Serial port connector
• 1x Tuning Controller Connector

Wireless LAN & Bluetooth:

• 1x PCIe x16 slot (From CPU)
  • Поддържа PCIe 4.0 за 11th Gen Intel^® CPU
  • Поддържа PCIe 3.0 за 10th Gen Intel^® CPU
• 1x PCIe 3.0 x1 slot (From B560 chpiset)

Съхранение:

• 6x порта SATA 6Gb / s (от чипсет B560)
• 2x M.2 slot (Key M)

 Памет:

• 4x DDR4 слота за памет, поддържат до 128GB
• Поддържа 1R 2133/2666/2933 MHz за 10-то поколение Intel® процесор (от JEDEC & POR)
• Поддържа 1R 2133/2666/2933/3200 MHz за 11-то поколение Intel® процесор (от JEDEC & POR)
• Максимална честота на овърклок:
  • 1DPC 1R Max speed up to 5066 MHz
  • 1DPC 2R Max speed up to 4600+ MHz
  • 2DPC 1R Max speed up to 4266+ MHz
  • 2DPC 2R Max speed up to 4000+ MHz
• Поддържа двуканален режим
• Поддържа не-ECC, не-буферирана памет
• Поддържа Intel® Extreme Memory Profile (XMP)
