Интерфейси:

• 1x PS/2 клавиатура/мишка
• 1x D-Sub
• 1x DVI-D
• 1x HDMI
• 6x USB 3.0
• 8x USB 2.0
• 6 x SATA III - Поддържа RAID 0, RAID 1, RAID 5, and RAID 10
• 1x RJ-45
• 6x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Слотове за разширение:

• 1x PCI Express x16 slot, running at x16 (PCIEX16)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
  (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
• 1x PCI Express x16 slot, running at x4 (PCIEX4)
  (The PCIEX4 slot conforms to PCI Express 2.0 standard.)
• 2x PCI slots

Конектори:

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 6x SATA 6Gb/s connectors
• 1x CPU fan header
• 3x system fan headers
• 1x front panel header
• 1x front panel audio header
• 1x S/PDIF Out header
• 1x USB 3.0/2.0 header
• 3x USB 2.0/1.1 headers
• 1x serial port header
• 1x parallel port header
• 1x Clear CMOS jumper
• 1x Trusted Platform Module (TPM) header
