Интерфейс:

• 2 x Thunderbolt™ 4 USB Type-C®
• 7 x USB 3.2 Gen 2 port(s) (6 x Type-A + 1 x USB Type-C®)
• 3 x USB 2.0 port(s) (3 x Type-A)
• 1 x HDMI^®
• 1 x Wi-Fi Module
• 1 x Marvell^® AQtion 10Gb Ethernet port
• 5 x Gold-plated audio jacks
• 1 x Optical S/PDIF out port
• 1 x BIOS FlashBack™ button
• 1 x Clear CMOS button

Wireless & Bluetooth:

• Intel® Wi-Fi 6E
• 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
• Поддържа честотна лента 2.4/5/6GHz*
• Bluetooth v5.2

Памет:

• 4 x DIMM, макс. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800MHz Non-ECC, Un -буферирана памет*
• Двуканална архитектура на паметта
• Поддържа Intel® Extreme Memory Profile (XMP)

Слотове за раширение:

• Процесори Intel® 12-то поколение:
  • 2 x PCIe 5.0 x16 слота (поддържа режими x16 или x8/x8)
• Intel® Z690 чипсет:

  • 4.0 x16 слот (поддържа режим x4 или x4/x4)

Съхранение:

• Общо поддържа 5 x M.2 слота и 6 x SATA 6Gb/s порта

Конектори:

• Fan and Cooling related
  1 x 4-pin CPU Fan header(s)
  1 x 4-pin CPU OPT Fan header(s)
  1 x 4-pin AIO Pump header(s)
  4 x 4-pin Chassis Fan header(s)
  1 x W_PUMP+ header(s)
  1 x 2-pin Water In header
  1 x 2-pin Water Out header
  1 x 3-pin Water Flow header
• Power related
  1 x 24-pin Main Power connector
  2 x 8-pin +12V Power connector
  1 x 6-pin PCIe Graphics Card connector
• Storage related
  3 x M.2 slots (Key M)
  6 x SATA 6Gb/s ports
• USB
  1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®)
  2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports
  2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
• Miscellaneous
  3 x Addressable Gen 2 header(s)
  1 x AURA RGB header(s)
  1 x FlexKey button
  1 x 12-1 pin Front Panel Audio header (AAFP)
  1 x ReTry button
  1 x SPI TPM header (14-1pin)
  1 x Start button
  1 x 10-1 pin System Panel header
  1 x Thermal Sensor header
