Интерфейси:

• 1x PS/2 клавиатура/мишка комбиниран порт

• 1x DVI-D
• 1x D-Sub
• 1x Thunderbolt port
• 1x HDMI
• 1x RJ-45

• 6x USB 3.0 (blue)
• 6x SATA 6Gb
• 2x SATA 6Gb
• Поддържа Raid 0, 1, 5, 10
• 1x S/PDIF изход
• 6x аудио жакове

• 1x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n and Bluetooth v4.0/3.0+HS)

Bluetooth:

• Bluetooth V4.0

• Bluetooth V3.0+HS

Wireless Data Network:

• Wi-Fi 802.11a/b/g/n/a

• Supports dual band frequency 2.4/5 GHz

Слотове за разширение:

• 3x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x4/x4)

• 4x PCIe 2.0 x1
• Поддържа NVIDIA Quad-GPU SLI технология
• Поддържа AMD Quad-GPU CrossFireX технология
• Поддържа AMD 3-Way CrossFireX технология

Конектори:

• 1x USB 3.0 connector support additional 2 USB 3.0 ports (19-pin)

• 4x USB 2.0 connectors supports additional 8 USB 2.0 ports

• 1x TPM header

• 8x SATA 6Gb/s connectors

• 1x CPU Fan connector (1 x 4 -pin)

• 1x CPU OPT Fan connector (1 x 4 -pin)

• 4x Chassis Fan connectors (4 x 4 -pin)

• 1x S/PDIF out header

• 1x 24-pin EATX Power connector

• 1x 8-pin ATX 12V Power connector

• 1x Front panel audio connector (AAFP)

• 1x System panel (Q-Connector)

• 1x DirectKey Button

• 1x DRCT header

• 1x MemOK! button

• 1x TPU switch

• 1x EPU switch

• 1x Power-on button

• 1x Clear CMOS jumper

• 1x USB BIOS Flashback button
