Интерфейси:

• 1 x PS/2 порт за мишка и клавиатура
• 1 x DVI-D порт
• 1 x HDMI порт
• 1 x LAN (RJ45) порта
• 1 x USB 3.1 Gen 2 Type-A,
• 1 x USB 3.1 Gen 1 USB Type-C^TM
• 2 x USB 3.1 Gen 1 (blue) Type-A
• 2 x USB 2.0
• 3 x Audio jack(s)

Слотове за разширение:

Конектори:

• 2 x Aura RGB Strip Header
• 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
• 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
• 2 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support
• 6 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s) (1 x 4 -pin)
• 2 x Chassis Fan connector(s) (2 x 4 -pin)
• 1 x S/PDIF out header(s)
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin ATX 12V Power connector(s)
• 1 x Front panel audio connector(s) (AAFP)
• 1 x System panel(s)
• 1 x Clear CMOS jumper(s)
• 1 x COM port header
• 1 x Speaker connector

Съхранение:

• AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
  1 x M.2 Socket 3, с M key, тип 2242/2260/2280 поддържани дискови устройства (SATA & PCIE 3.0 x 4 режим)
• AMD Athlon™ with Radeon™ Vega Graphics Processors :
  1 x M.2 Socket 3, с M key, тип 2242/2260/2280 поддържани дискови устройства (SATA режим)
• AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
  2 x SATA 6Gb/s порта
  Поддържа Raid 0, 1, 10
• AMD B450 chipset :
  1 x M.2 Socket 3, с M key, тип 2242/2260/2280 поддържани дискови устройства (SATA & PCIE 3.0 x 2 режим)
  4 x SATA 6Gb/s порта
  Поддържа Raid 0, 1, 10
