Интерфейси:

• 1 x PS/2 keyboard/mouse port
• 1 x D-Sub port
• 1 x DVI-D port
• 1 x HDMI port
• 6 x USB 3.1 Gen 1 ports
• 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
• 1 x USB 3.1 Gen 2 Type-A port (red)
• 1 x RJ-45 port
• 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Слотове за разширение:

• 1 x PCI Express x16 slot, running at x16 (PCIEX16)
• 1 x PCI Express x16 slot, running at x4 (PCIEX4)
• 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• 2 x PCI slots

Конектори:

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x M.2 Socket 3 connector
• 1 x SATA Express connector
• 6 x SATA 6Gb/s connectors
• 1 x CPU fan header
• 3 x system fan headers
• 1 x front panel header
• 1 x front panel audio header
• 1 x S/PDIF Out header
• 2 x USB 3.1 Gen 1 headers
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module (TPM) header
• 1 x serial port header
• 1 x parallel port header
• 1 x Clear CMOS jumper

Съхранение:

• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
• 1 x SATA Express connector
• 6 x SATA 6Gb/s connectors
• Support for RAID 0, RAID 1, RAID 5, and RAID 10



Памет:

• 4 x DDR4 DIMM сокети, поддържащи до 64 GB системна памет
• Двуканална архитектура на паметта
• Поддръжка за DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 модули памет

• Поддръжка заECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
• Поддръжка за non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Поддръжка за Extreme Memory Profile (XMP) memory modules
