Интерфейси:

• 1x DisplayPort

• 1x HDMI

• 2x RJ-45

• 6x USB 3.0 (blue)

• 4x USB 2.0

• 6x SATA 6Gb
• Поддържа Raid 0, 1, 5, 10
• 1x S/PDIF изходи

• 1x Bluetooth V4.0 connector for ASUS Wi-Fi GO! card

• 1x USB BIOS Flashback Button

• 1x Mini DisplayPort

Bluetooth:

• Bluetooth V4.0

• Bluetooth V3.0+HS

Wireless Data Network:

• Wi-Fi 802.11a/b/g/n/a

• Supports dual band frequency 2.4/5 GHz

Слотове за разширение:

• 2x PCIe 3.0/2.0 x16 (x16 or dual x8)
• 1x PCIe 2.0 x16 (x4 mode)
• 4x PCIe 2.0 x1
• Поддържа NVIDIA Quad-GPU SLI технология
• Поддържа AMD Quad-GPU CrossFireX технология
• Поддържа AMD 3-Way CrossFireX технология

Конектори:

• 1x USB 3.0 connector support additional 2 USB 3.0 port(s) (19-pin)

• 2x USB 2.0 connectors support(s) additional 4 USB 2.0 port(s)

• 1x TPM header

• 10x SATA 6Gb/s connectors

• 1x CPU Fan connector (1 x 4 -pin)

• 1x CPU OPT Fan connector (1 x 4 -pin)

• 4x Chassis Fan connectors (4 x 4 -pin)

• 1x S/PDIF out header

• 1x 24-pin EATX Power connector

• 1x 8-pin ATX 12V Power connector

• 1x Front panel audio connector(s) (AAFP)

• 1x System panel (Q-Connector)

• 1x DirectKey Button

• 1x DRCT header

• 1x MemOK! button

• 1x TPU switch

• 1x EPU switch

• 1x Power-on button

• 1x Reset button

• 1x Clear CMOS button
