Интерфейс:

• 1 x Thunderbolt™ 4 USB Type-C
• 1 x USB 3.2 Gen 2x2 (1 x USB Type-C)
• 8 x USB 3.2 Gen 2 (7 x Type-A + 1 x USB Type-C)
• 1 x HDMI
• 1 x ASUS Wi-Fi Module
• 1 x Intel® 2.5Gb Ethernet
• 1 x Marvell® AQtion 10Gb Ethernet port
• 5 x LED-illuminated audio jacks
• 1 x Optical S/PDIF out
• 1 x BIOS FlashBack™ button
• 1 x Clear CMOS button

Wireless & Bluetooth: Intel® Wi-Fi 6E

Памет:

• 4 x DIMM, макс. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/5000(OC)/4800 Non-ECC, Un -буферирана памет*
• Двуканална архитектура на паметта
• Поддържа Intel® Extreme Memory Profile (XMP)
• OptiMem III

Слотове за раширение:

• Процесори Intel® 12-то поколение:
  • 2 x PCIe 5.0 x16 слота (поддържа режими x16 или x8/x8)
• Intel® Z690 чипсет:
  • 1 x PCIe 3.0 x1 слот

Съхранение: Общо поддържа 5 x M.2 слота и 6 x SATA 6Gb/s порта

• Процесори Intel® 12-то поколение:

• M.2_1 slot (Key M), type 2242/2260/2280/22110

  - Intel® 12th Gen processors support PCIe 5.0 x4 mode

• M.2_2 slot (Key M), type 2280

  - Intel® 12th Gen processors support PCIe 4.0 x4 mode

  Чипсет Intel® Z690:
• M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 & SATA modes)
• DIMM.2_1 slot (Key M) via ROG DIMM.2, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
• DIMM.2_2 slot (Key M) via ROG DIMM.2, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

• 6 x SATA 6Gb/s ports

Конектори:

• 2 x 4-pin Chassis Fan headers

• 2 x 4-pin Radiator Fan headers

• 2 x W_PUMP+ headers

• 1 x WB_SENSOR header

• 1 x 2-pin Water In header

• 1 x 2-pin Water Out header

• 1 x 3-pin Water Flow header

• 1 x 24-pin Main Power connector

• 2 x 8-pin +12V Power connector

• 1 x 6-pin PCIe Graphics Card connector

• 3 x M.2 slots (Key M)

• 1 x DIMM.2 slot supports 2 x M.2 slots (Key M)

• 6 x SATA 6Gb/s ports

• 1 x 6-pin ARGB Gen 2 header to support 2 x ARGB Gen 2 headers



• 1 x Addressable Gen 2 header



• 1 x AURA RGB header



• 1 x WB_ADD header



• 1 x BIOS Switch button



• 2 x BCLK button



• 1 x FlexKey button



• 1 x Front Panel Audio header (AAFP)



• 1 x LN2 Mode jumper



• 1 x Osc sence header



• 12 x ProbeIt Measurement Points



• 1 x ReTry button



• 1 x RSVD switch



• 1 x RSVD header



• 1 x Safe Boot button



• 1 x Slow Mode switch



• 1 x Start button



• 1 x V_Latch switch



• 1 x 10-1 pin System Panel header



• 1 x Thermal Sensor header
