Интерфейси:

• 1 x DisplayPort
• 1 x HDMI
• 1 x LAN (RJ45) port(s)
• 1 x USB 3.1 Gen 2 (червен) Type-A
• 1 x USB 3.1 Gen 2 (черен) USB Type-C
• 4 x USB 3.1 Gen 1 (син)
• 4 x USB 2.0
• 1 x Optical S/PDIF out
• 5 x аудио жака
• 1 x Clear CMOS button(s)
• 1 x USB BIOS Flashback Button(s)
• 1 x ASUS 2x2 Wi-Fi 802.11 a/b/g/n/ac и Bluetooth v4.2 module

Слотове за разширение:

• 2 x PCIe 3.0 x16 (x16, x8/x8, or x8/x4+x4)
• 1 x PCIe 3.0 x16 (x4 режим, черен)
• 1 x PCIe 3.0 x1

Конектори:

• 2 x Aura Addressable Strip Header(s)
• 2 x Aura RGB Strip Headers
• 2 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
• 6 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s)
• 1 x CPU OPT Fan connector(s)
• 1 x Chassis Fan connector(s)
• 1 x Optional Fan connector(s)
• 1 x AIO_PUMP connector
• 1 x H_AMP fan connector
• 1 x W_PUMP+ connector
• 1 x 4-pin EATX 12 V Power connector
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin EATX 12V Power connectors
• 1 x Front panel audio connector(s) (AAFP)
• 1 x 5-pin EXT_FAN(Extension Fan) connector
• 1 x MemOK! II switch(es)
• 1 x Thermal sensor connector(s)
• 1 x Node Connector(s)
• 1 x 5-pin EXT_FAN(Extension Fan) connector
• 1 x ReTry button
• 1 x System panel connector
• 1 x T_Sensor Connector
• 1 x W_IN header
• 1 x W_OUT header
• 1 x W_FLOW header
• 1 x USB 3.1 Gen 2 front panel connector
• 2 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
• 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
• 1 x Start button
• 1 x Reset button
• 1 x Q-Code

Съхранение:

Комплектът включва:

• 1 x ROG logo plate sticker
• 1 x 2-Way SLI bridge(s)
• 4 x SATA 6Gb/s cable(s)
• 1 x M.2 Screw Package
• 1 x Supporting DVD
• 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
• 1 x Q-Connector
• 1 x Extension Cable for RGB strips (80 cm)
• 1 x Extension cable for Addressable LED
• 1 x ROG coaster(s)
• 1 x USB 3.1 Gen 1 Header to USB 2.0 adapter cable
• 2 x ROG weave SATA 6G cable
• 1 x ROG Thank you card

Wi-Fi/ Bluetooth:

• Wi-Fi 802.11 a/b/g/n/ac
• Поддържа двубандова честота 2.4/5 GHz
• Поддържа канална честотна лента HT20/HT40/HT80/HT160
• Bluetooth V5.0
