Интерфейси:

• 1 x DisplayPort
• 1 x HDMI
• 1 x LAN (RJ45) порта
• 4 x USB 3.1 Gen 1
• 4 x USB 2.0
• 1 x Optical S/PDIF out
• 5 x аудио жака
• 1 x ASUS 2x2 Wi-Fi 802.11 a/b/g/n/ac и Bluetooth v4.2 модул

Слотове за разширение:

• 1 x PCIe 3.0 x16

Конектори:

• 1 x Aura Addressable Strip Header(s)
• 1 x AAFP connector
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)
• 4 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s)
• 1 x Chassis Fan connector(s)
• 1 x AIO_PUMP connector
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin ATX Power connector
• 1 x System panel(s)
• 1 x Clear CMOS jumper(s)
• 1 x T_Sensor Connector
• 1 x USB 3.1 Gen 2 front panel connector
• 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
• 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

Съхранение:

Intel Z370 чипсет

• 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*¹
• 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*¹
• 4 x SATA 6Gb/s port(s)
• Подържа Raid 0, 1, 5, 10
• Intel Rapid Storage Technology
• Поддържа Intel Smart Response Technology
• Intel Optane Memory Ready

Памет:

• 2 x DIMM, Max. 32GB, DDR4
• 4333(O.C.)/4200(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133(O.C.) MHz Non-ECC, небуферирана памет
• Двуканална архитектура на паметта
• Поддържа Intel Extreme Memory Profile (XMP)
