Интерфейси:

• 1 x PS/2 keyboard/mouse combo port(s)
• 1 x DVI-D
• 1 x DisplayPort
• 1 x HDMI
• 1 x LAN (RJ45) port(s)
• 2 x USB 3.1 Type-A + Type-C
• 2 x USB 3.0 (blue)
• 4 x USB 2.0
• 1 x Optical S/PDIF out
• 5 x Audio jack(s)

Слотове за разширение:

• 1 x PCIe 3.0/2.0 x16 (x16 mode)
• 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
• 4 x PCIe 3.0/2.0 x1

Конектори:

• 1 x AAFP connector
• 1 x RGB Header(s)
• 2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s)
• 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
• 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
• 6 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s)
• 1 x CPU OPT Fan connector(s)
• 2 x Chassis Fan connector(s)
• 1 x AIO_PUMP connector
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin ATX 12V Power connector(s)
• 1 x System panel(s) (Chassis intrusion header is inbuilt)
• 1 x Clear CMOS jumper(s)
• 1 x 5-pin EXT_FAN(Extension Fan) connector
• 1 x ROG extension (ROG_EXT) header(s)
• 1 x 14-1 pin TPM connector
• 1 x COM port header
• 1 x T_Sensor Connector
• 3 x 3D Mount screw port(s)

Съхранение:

• 1 x M.2 Socket 3, с M Key, тип 2242/2260/2280 поддържани дискови устройстваt (SATA & x2 PCIE режим)
• 1 x M.2 Socket 3, с M key, тип 2242/2260/2280/22110 поддържани дискови устройства (PCIE 3.0 x 4 режим)
• 6 x SATA 6Gb/s порта
• Поддържа Raid 0, 1, 5, 10
• Intel Rapid Storage Technology 15
• Intel Optane Memory Ready


Комплектът включва:

• 4 x SATA 6Gb/s cable(s)
• 1 x M.2 Screw Package
• 1 x Supporting DVD
• 1 x ROG Strix stickers
• 1 x 10 in 1 ROG Cable Label(s)
• 1 x Extension Cable for RGB strips (80 cm)
• 1 x 3D printing mount package

Аудио:

• ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
