Интерфейси:

• 1x PS/2 мишка/клавиатура
• 1x D-Sub
• 1x DVI-D
• 1x HDMI
• 1x Optical SPDIF Out
• 2x USB 2.0
• 4x USB 3.0
• 1x RJ-45
• HD аудио жакове: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• 5x SATA3 6.0 Gb/s, поддържа RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 13 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug

WI-Fi:

• Поддържа IEEE 802.11a/b/g/n/ac
• Поддържа Dual-Band (2.4/5 GHz)
• Поддържа висока скорост на връзка - до 433Mbps
• Поддържа Bluetooth 4.0 / 3.0 + High speed class II

Слотове за разширение:

• 1x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
• 1x Vertical Half Mini-PCI Express Slot: For WiFi + BT Module

Конектори:

• 1x Chassis Intrusion Header
• 1x TPM Header
• 1x CPU Fan Connector (4-pin)
• 1x Chassis Fan Connector (4-pin)
• 1x 24 pin ATX Power Connector
• 1x 4 pin 12V Power Connector
• 1x Front Panel Audio Connector
• 1x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
• 1x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))

Съхранение:

•  5 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 13 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug

Комплекта включва:

• I/O Shield
• 2 x SATA Data кабел
• 1 x WiFi-802.11ac модул
• 2 x SMA WiFi кабели за антена
• 2 x ASRock WiFi 2.4/5 GHz антени
• 1 x WiFi Module Bracket
• 2 x Screws for WiFi модул
