Интерфейси:

• 2 x антенни портове
• 1 x PS/2 мишка/клавиатура
• 1 x D-Sub
• 1 x DVI-D
• 1 x HDMI
• 1 x оптичен SPDIF изход
• 1 x USB 3.1 Type-A Port (10 Gb/s) (ASMedia ASM2142) (поддържа  ESD защита (ASRock Full Spike Protection))
• 1 x USB 3.1 Type-C Port (10 Gb/s) (ASMedia ASM2142) (поддържа  ESD защита (ASRock Full Spike Protection))
• 4 x USB 3.0 Ports (Intel^® Z270) (поддържа  ESD Protection (ASRock Full Spike защита ))
• 1 x RJ-45 LAN Port с LED (ACT/LINK LED и SPEED LED)
• HD аудио жакове: заден говорител/централен/ бас/ вход / преден говорител / микрофон

Слотове за разширение:

• 3 x PCI Express 3.0 x16 слотове (PCIE2/PCIE4/PCIE6: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4); triple at x8 (PCIE2) / x8 (PCIE4) / x4 (PCIE6))
• 3 x PCI Express 3.0 x1 слотове (Flexible PCIe)
• Поддържа AMD Quad CrossFireX, 3-Way CrossFireX и CrossFireX
• Поддържа NVIDIA Quad SLI и SLI
• 1 x M.2 Socket (Key E), поддържа тип 2230 WiFi/BT модул
• 15μ Gold Contact in VGA PCIe Slot (PCIE2)

Конектори:

• 1 x COM Port Header
• 1 x TPM Header
• 1 x Power LED and Speaker Header
• 1 x AURA RGB LED Header
• 1 x CPU Fan Connector (4-pin)
• 1 x CPU Optional/Water Pump Fan Connector (4-pin)
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
• 1 x Chassis Optional/Water Pump Fan Connector (4-pin)
• 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
• 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
• 1 x Thunderbolt AIC Connector (5-pin)
• 1 x Thunderbolt AIC Connector (10-pin)
• 3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Intel^® Z270) (Supports ESD Protection (ASRock Full Spike Protection))
• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Intel^® Z270) (Supports ESD Protection (ASRock Full Spike Protection))
• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (ASMedia ASM1074 hub) (Supports ESD Protection (ASRock Full Spike Protection))

Съхранение:

• 6 x SATA3 6.0 Gb/s конектора , поддържащи RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 и Intel Smart Response Technology), NCQ, AHCI и Hot Plug
• 2 x SATA3 6.0 Gb/s конектора от ASMedia ASM1061, поддържащи NCQ, AHCI и Hot Plug
• 1 x Ultra M.2 Socket (M2_1), поддържащ M Key тип 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s модул и M.2 PCI Express модул до Gen3 x4 (32 Gb/s)
• 1 x Ultra M.2 Socket (M2_2), поддържащ M Key тип 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s модул и M.2 PCI Express модул до Gen3 x4 (32 Gb/s)

Памет:

• 4 цокъла DDR4 DIMM, поддържащи до 64 GB системна памет
• Поддръжка на модули памет DDR4 3866+(OC)*/3733(OC)/3600(OC)/3200(OC)/2933(OC)/2800(OC)/2400**/2133 non-ECC, небуферирана памет

*7ма генерация  Intel CPU поддържа DDR4 до 2400;6та генерация Intel CPU поддържа DDR4 до 2133Mhz

Комплекта включва:

• Quick Installation Guide, Support CD, I/O Shield
• 4 x SATA Data Cables
• 1 x ASRock SLI_HB_Bridge_2S Card
• 3 x Screws for M.2 Sockets
