Интерфейс:

Поддържа AMD® CrossFire™ Технология

Памет:

• 4x DIMM DDR4 слота, поддържа до 128GB
• Поддържа 1R 2133/2666/3200 MHz (by JEDEC & POR)
• Максимална честота на овърклок:

  • 1DPC 1R Max speed up to 4800+ MHz
  • 1DPC 2R Max speed up to 4000+ MHz
  • 2DPC 1R Max speed up to 4000+ MHz
  • 2DPC 2R Max speed up to 3600+ MHz
• Двуканална архитектура
• Поддържа non-ECC, небуферирана
• Поддържа Intel^® Extreme Memory Profile (XMP)

Слотове за разширение:

• 2x PCIe x16 слота
• 1x PCIe 3.0 x1 слот (Fom B660 chipset)


Съхранение:

• 4x SATA 6Gb/s порта (From B660 chipset)
• 2x M.2 слота (Key M)
• Поддръжка на технологията Intel® Smart Response за процесори Intel Core™
• Поддържа RAID 0, RAID 1, RAID 5 and RAID 10


LED спецификации:

• 1x 4-pin RGB LED конектор
• 2x 3-pin RAINBOW LED конектори
• 4x EZ Debug LED

Конектори:

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 1x 4-pin ATX 12V power connector
• 4x SATA 6Gb/s connectors
• 2x M.2 slots (M-Key)
• 1x USB 3.2 Gen 1 5Gbps Type-C port
• 1x USB 3.2 Gen 1 5Gbps Type-A connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
• 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1x 4-pin CPU fan connector
• 1x 4-pin water-pump fan connector
• 2x 4-pin system fan connectors
• 1x Front panel audio connector
• 2x System panel connectors
• 1x Chassis Intrusion connector
• 1x TPM module connector
• 1x Clear CMOS jumper
• 1x TBT connector (supports RTD3)
• 1x Serial port
• 1x Tuning Controller connector
