Интерфейси (заден панел):

• 1x PS/2 клавиатура
• 1x PS/2 мишка
• 4x USB 2.0
• 2x USB 3.0
• 1x VGA поддържа резолюция 1920x1200 @60Hz, 24bpp
• 1x DVI-D поддържа максимална резолюция  2560 x1600 @60Hz, 24bpp/ 1920x1200 @ 60Hz, 24bpp
• 1x HDMI поддържа максимална резолюция 4096x2160@24Hz, 36bpp/ 3840x2160@30Hz, 36bpp/ 1920x1200@120Hz, 36bpp and 1920x1200@60Hz, 36bpp
• 1x LAN (RJ45)
• 3x аудио жакове
• 6x SATA 6Gb/s -  поддържа RAID 0/1/5/10

Слотове за разширение:

• 2 x PCIe x16 slots

- PCI_E2 supports PCIe 3.0 x16 speed (Only FM2+ processors can support PCIe 3.0)
- PCI_E4 supports PCIe 2.0 x4 speed

• 2 x PCIe 2.0 x1 slots
• 3 x PCI slots

Конектори:

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 6x SATA 6Gb/s connectors
• 3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
• 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
• 1x 4-pin CPU fan connector
• 2x 4-pin system fan connectors
• 1x 3-pin system fan connector
• 1x Front panel audio connector
• 2x System panel connectors
• 1x Chassis Intrusion connector
• 1x TPM module connector
• 1x Serial port connector
• 1x Parallel port connector
• 1x Clear CMOS jumper
• 2x USB power jumper
