Интерфейси:

• 1 x PS/2 keyboard/mouse port
• 1 x D-Sub port
• 1 x DVI-D port
• 1 x HDMI port
• 4 x USB 3.1 Gen 1 ports
• 2 x USB 2.0/1.1 ports
• 1 x RJ-45 port
• 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Слотове за разширение:

• 1 x PCI Express x16 slot, running at x16 (PCIEX16)



• 2 x PCI Express x16 slot, running at x4 (PCIEX4_1, PCIEX4_2)
• 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• 1 x PCI slot



Конектори:

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x M.2 Socket 3 connector
• 1 x SATA Express connector
• 6 x SATA 6Gb/s connectors
• 1 x CPU fan header
• 3 x system fan headers
• 1 x front panel header
• 1 x front panel audio header
• 1 x S/PDIF Out header
• 2 x USB 3.1 Gen 1 headers
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module (TPM) header
• 1 x serial port header
• 1 x parallel port header
• 1 x Clear CMOS jumper

Съхранение:

1. 8 x USB 3.1 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

Памет:

• 4цокъла DDR4 DIMM, поддържащи до 64 GB системна памет
• Поддръжка на модули памет DDR4 2400(O.C.)* / 2133 MHz

*7th Gen Intel CPU поддържа DDR4 до 2400; 6^th Gen Intel CPU поддържа DDR4 до 2133.
