Интерфейси:

Слотове за разширение:

2 x PCIe 4.0/3.0 x16 (x16, x8/x8, x8/x4) + 1 x PCIe 3.0 x16 (max. x4)

Intel® 11^th и 10^th поколение:

• 2 x PCIe 4.0/3.0 x16 slot(s)*

- Intel® 11th processors support PCIe 4.0 x16 or x8/x8 or x8/x4 mode(s)

- Intel®10th processors support PCIe 3.0 x16 or x8/x8 or x8/x4 mode(s)

Intel® Z590 Chipset:

• 1 x PCIe 3.0 x16 slot (supports x4 mode)**

Конектори:

1 x Thunderbolt 4 (onboard)

Вентилатор и охлаждане:

• 1 x 4-pin CPU Fan header(s)
• 1 x 4-pin CPU OPT Fan header(s)
• 1 x 4-pin AIO Pump header(s)
• 3 x 4-pin Chassis Fan header(s)
• 1 x VRM heatsink Fan header
• 1 x W_PUMP+ header

Свързани с мощността:

• 1 x 24-pin Main Power connector
• 1 x 8-pin +12V Power connector
• 1 x 4-pin +12V Power connector

Свързани със съхранението:

• 4 x M.2 slots (Key M)
• 6 x SATA 6Gb/s ports

USB:

• 1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C®)
• 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports

Други:

• 3 x AURA Addressable Gen 2 header(s)
• 1 x AURA RGB header(s)
• 1 x CPU Over Voltage jumper
• 1 x Front Panel Audio header (AAFP)
• 1 x Q Code
• 1 x SPI TPM header (14-1pin)
• 1 x 20-3 pin System Panel header with Chassis intrude function
• 1 x Thermal Sensor header
• 1 x Thunderbolt header

Съхранение:

Intel®11th и 10th поколение:

• Поддържа 4 x M.2 слота и 6 x SATA 6Gb/s порта

• M.2_1 slot (Key M), type 2242/2260/2280/22110

• M.2_2 slot (Key M), type 2242/2260/2280/22110

Intel® Z590 Chipset:

• M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode)
• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)*
• 6 x SATA 6Gb/s ports

Памет:

• 4x DDR4 (Dual channel)
• Max Memory Size: 128GB
