Wireless & Bluetooth:

• 2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2

• Wi-Fi 6E

• 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax

• Поддържа честотна лента 2.4/5/6GHz

• Bluetooth v5.2


Памет:

• 4 x DIMM, макс. 128GB, DDR5 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Не-ECC, небуферирана памет
• Двуканална архитектура на паметта
• Поддържа Intel® Extreme Memory Profile (XMP)
• OptiMem III

Слотове за разширение:

• Процесори Intel® 12-то поколение:
  • 1 x PCIe 5.0 x16 слот
• Intel® Z690 чипсет:

  • 1 x PCIe 3.0 x16 слот (поддържа режим x4 или x4/x4 режим)

  • 1 x PCIe 3.0 x1 слот

Съхранение:

• Процесори Intel® 12-то поколение:

• M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

• Чипсет Intel® Z690:

• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

• M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)*

• 6 x SATA 6Gb/s порта
• Поддържа NVMe RAID 0/1/5, SATA RAID 0/1/5/10

Конектори:

• Fan and Cooling related

1 x 4-pin CPU Fan header

1 x 4-pin CPU OPT Fan header

1 x 4-pin AIO Pump header

5 x 4-pin Chassis Fan headers

• Power related

1 x 24-pin Main Power connector

2 x 8-pin +12V Power connector

• Storage related

4 x M.2 slots (Key M)

6 x SATA 6Gb/s ports

• USB

1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®)

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 headers support additional 4 USB 2.0 ports

• Miscellaneous

3 x Addressable Gen 2 headers

1 x AURA RGB header

1 x BMC header

1 x CPU Over Voltage jumper

1 x Front Panel Audio header (AAFP)

1 x SPI TPM header (14-1pin)

1 x 20-3 pin System Panel header with Chassis intrude function

1 x Thermal Sensor header

1 x Thunderbolt header
