• 1 x 4-pin CPU Fan header(s)
• 1 x 4-pin CPU OPT Fan header(s)
• 1 x 4-pin AIO Pump header(s)
• 4 x 4-pin Chassis Fan header(s)
• 1 x VRM heatsink Fan header
• 1 x 24-pin Main Power connector
• 1 x 8-pin +12V Power connector
• 1 x 4-pin +12V Power connector
• 3 x M.2 slots (Key M)
• 6 x SATA 6Gb/s port
• 1 x USB 3.2 Gen 1 connector (support(s) USB Type-C®)
• 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
• 3 x AURA Addressable Gen 2 header(s)
• 1 x AURA RGB header(s)
• 1 x Clear CMOS header
• 1 x CPU Over Voltage jumper
• 1 x Front Panel Audio header (AAFP)
• 1 x SPI TPM header (14-1pin)
• 1 x 20-3 pin System Panel header with Chassis intrude function
• 1 x Thermal Sensor header
• 1 x Thunderbolt header
• 1 x S/PDIF out header

Съхранение:

• Intel®11th Gen: M.2_1 slot (Key M), type 2242/2260/2280/22110

- Only Intel® 11th Core™ processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs.

• Intel Z590 Chipset:

M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*

M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)**

6 x SATA 6Gb/s ports

Памет:

• DDR4 5333(OC)5133(OC)/5000(OC)/4800(OC)/4600(OC)/4500(OC)/4400(OC)/4267(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*
•   Двуканална архитектура на паметта
• Поддържа Intel® Extreme Memory Profile (XMP)
• OptiMem II

Wireless & Bluetooth:

• Intel Wi-Fi 6

• 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)


• Поддържа честотна лента 2,4 / 5GHz

• Bluetooth v5.0 или по-нова
