Интерфейси:

• 1 x LAN (RJ45) port(s)
• 1 x USB 3.1 Gen 2 (black)TypeC^™
• 3 x USB 3.1 Gen 2 (red)Type-A
• 8 x USB 3.1 Gen 1 (blue)
• 1 x Optical S/PDIF out
• 1 x Clear CMOS button(s)
• 1 x USB BIOS Flashback^® Button(s)
• 1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v5.0
• 5 x LED-illuminated audio jacks
• 1 x Aquantia AQC-107 10G LAN port

Слотове за разширение:

• AMD Ryzen Threadripper процесори
  4 x PCIe 3.0 x16 (x16, x16/x16, x16/x8/x16, x16/x8/x16/x8)
• AMD X399 chipset
  1 x PCIe 3.0 x4

Конектори:

• 1 x WB_SENSOR
• 2 x Aura Addressable Strip Header(s)
• 2 x Aura RGB Strip Headers
• 2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
• 2 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
• 8 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s)
• 1 x CPU OPT Fan connector(s)
• 2 x Chassis Fan connector(s)
• 1 x H_AMP fan connector
• 1 x W_PUMP+ connector
• 2 x 8-pin EATX 8 V Power connector
• 1 x 24-pin EATX Power connector(s)
• 1 x Front panel audio connector(s) (AAFP)
• 1 x Slow Mode switch(es)
• 7 x ProbeIt Measurement Points
• 2 x Thermal sensor connector(s)
• 1 x EZ Plug connector(s) (4-pin Molex power connector)
• 1 x Reset button(s)
• 1 x BIOS Switch button(s)
• 1 x Node Connector(s)
• 1 x LN2 Mode jumper(s)
• 1 x Safe Boot button
• 1 x ReTry button
• 1 x 14-1 pin TPM connector
• 1 x Slow Mode jumper(s)
• 1 x System panel connector
• 1 x W_IN header
• 1 x W_OUT header
• 1 x W_FLOW header
• 1 x Start button
• 1 x USB 3.1 Gen 2 front panel connector
• 1 x DIMM.2 Slot supports 2 M.2 drives (2242-22110)
• 1 x RSVD Switch
• 1 x 4-Pin HS fan connector

Съхранение:

• AMD Ryzen Threadripper процесори:
  2 x M.2 Socket 3, с M Key design, тип 2242/2260/2280/22110 поддържащи дискови устройства (поддържа SATA & PCIE SSD)
  1 x M.2 Socket 3, с M key, тип 2242/2260/2280 поддържащи дискови устройства (SATA & PCIE режим)
• AMD X399 chipset:
  8 x SATA 6Gb/s конектори
  Поддържа Raid 0, 1, 10
