Интерфейси:

• 1 x PS/2 порт за клавиатура (лилав)
• 1 x PS/2 порт за мишка (зелен)
• 1 x DVI-D
• 1 x D-Sub
• 1 x DisplayPort
• 1 x HDMI
• 1 x LAN (RJ45)
• 4 x USB 3.0 (сини)
• 2 x USB 2.0

• 3 x аудио жака

Слотове за разширение:

Конектори:

• 1 x MONO out header
• 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
• 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)
• 1 x LPT header
• 2 x COM port(s) connector(s)
• 6 x SATA 6Gb/s connector(s)
• 1 x CPU Fan connector(s) (1 x 4 -pin)
• 2 x Chassis Fan connector(s) (2 x 4 -pin)
• 1 x 24-pin EATX Power connector(s)
• 1 x 4-pin ATX 12V Power connector(s)
• 1 x Front panel audio connector(s) (AAFP)
• 1 x Internal speaker connector(s)
• 1 x System panel(s)
• 1 x Chassis Intrusion connector(s)
• 1 x 14-1 pin TPM connector

Съхранение:

• 1 x M.2 Socket 3, with M key, type 2242/2260/2280 поддържани дискови устройства (SATA & PCIE режим)
• 1 x M.2 Socket 3, с M Key, тип 2242/2260/2280 поддържани дискови устройства (x4 PCIE режим)
• 6 x SATA 6Gb/s порта
• Intel Optane Memory Ready

Комплектът включва:

• I/O Shield
• 2 x SATA 6Gb/s cable(s)
• 1 x M.2 Screw Package
• 1 x Supporting DVD

Аудио:

• Realtek ALC887 8-Channel High Definition Audio CODEC
