Интерфейс:

• 2 x USB 3.1 (1 port at Type A, 1 port at Type C)
• 4 x USB 3.0
• 1 x HDMI
• 1 x DisplayPort
• 1 x DVI-D
• 1 x VGA
• 2 x RJ-45
• 8-channel Audio I/O ports (5+1 Audio jacks)

Конектори:

• 2 x USB 2.0 pin header
• 1 x USB 3.0 pin header
• 1 x M.2 Connector , NGFF Type : 2280/2260/2242
• 1 x M.2 Connector , NGFF Type : 22110/2280/2260/2242
• 1 x TPM header
• 1 x PSU Power Connector (24-pin ATX power connector)
• 1 x COM port
• 1 x USB BIOS Flashback Button
• 1 x S/PDIF Out (Optical)
• 1 x COM port

Памет:

• 4 x Двуканален DDR4 2666/2400 UDIMM без ECC и с ECC

• Максимум до 128 GB UDIMM

• Memory Size: 32GB, 16GB, 8GB

Слотове за разширение:

• Slot Location 1 : PCI-E x1 (Gen3 X1 Link)

• Slot Location 2 : PCI-E x16 (Gen3 X16 + X8 Link)

• Slot Location 3 : PCI-E x16 (Gen3 X8 Link)

• Slot Location 4 : PCI-E x1 (Gen2 X1 Link)

• Slot Location 5 : PCI-E x16 (Gen3 X4 Link)

• Slot Location 6 : PCI-E x4 (Gen1 X4 Link)

Съхранение:

• SATA Controller : Intel® C246 Chipset, 8x SATA3 6Gb/s ports
